Another outbreak of pyrocumulonimbus clouds in Australia

January 4th, 2020 | Scott Bachmeier

Himawari-8 “Red” Visible (0.64 µm, left) and Shortwave Infrared (3.9 µm, right) images [click to play animation | MP4]

Following a multi-day outbreak in late December 2019, Australian bushfires flared up again across far eastern Victoria and far southeastern New South Wales (along and ahead of a cold frontal passage) on 04 January 2020. A JMA Himawari-8 Target Sector was positioned over that region, providing images at 2.5-minute intervals — “Red” Visible (0.64 µm) images displayed the large smoke plumes with embedded pyro-convection, while Shortwave Infrared (3.9 µm) images revealed the widespread fire thermal anomalies or “hot spots” (clusters of red pixels).

Himawari-8 Shortwave Infrared (3.9 µm) and “Clean” Infrared Window (10.4 µm) images (below) showed the development of 2 pyrocumulonimbus (pyroCb) clouds — the first over southern New South Wales west of Cooma (station identifier YCOM), and the second to the southwest of YCOM (near the border between Victoria and New South Wales). The second pyroCb eventually exhibited cloud-top infrared brightness temperature (IRBT) values of -70ºC and colder (purple pixels). To be classified as a pyroCb, a deep convective cloud must be generated by a large/hot fire, and eventually exhibit cloud-top 10.4 µm IRBTs of -40ºC and colder (thus assuring the heterogeneous nucleation of all supercooled water droplets to ice crystals within the thunderstorm anvil).

Himawari-8 Shortwave Infrared (3.9 µm, top) and “Clean” Infrared Window (10.4 µm, bottom) images [click to play animation | MP4]

An aircraft flying very near or through one of these pyroCb clouds experienced severe turbulence:

On 4th Jan a @Qantas flight between Melbourne – Canberra flew through a PyroCB: A large, energetic, thunderstorm triggered by the #AustralianFires, causing severe turbulence: https://t.co/VvrsStWXK9

Here’s how it looked from space. Storm encounter was at approx. 07:47 UTC. pic.twitter.com/shuDaCk1ti

— SatWx Aviation (@SatWx_Aviation) January 6, 2020

Farther to the north, another pyroCb developed near Nowra, New South Wales (YSNW) — which briefly exhibited a -40ºC cloud-top IRBT at 0319 UTC, but then re-intensified around 08 UTC (below).

Himawari-8 Shortwave Infrared (3.9 µm, top) and “Clean” Infrared Window (10.4 µm, bottom) images [click to play animation | MP4]

In a sequence of VIIRS True Color Red-Green-Blue (RGB) and Infrared Window (11.45 um) images from NOAA-20 and Suomi NPP as viewed using RealEarth (below), the Nowra pyroCb was less ambiguous during the 03-04 UTC time period — and the aforementioned pair of pyroCbs straddling the border between Victoria and New South Wales were also evident.

Sequence of VIIRS True Color RGB and Infrared Window (11.45 um) images from NOAA-20 and Suomi NPP [click to enlarge]

===== 06 January Update =====

GOES-16 Natural Color RGB images + Smoke Detection derived product [click to play animation | MP4]

On 06 January, GOES-16 (GOES-East) Natural Color RGB images (above) displayed the hazy signature of high-altitude smoke (originating from previous episodes of Australian fires) over parts of Chile and Argentina — and the corresponding GOES-16 Smoke Detection derived product flagged much of this feature as “High Confidence” smoke (red).

In addition, GOES-17 (GOES-West) True Color RGB images created using Geo2Grid (below) showed a dense pall of smoke over the South Pacific Ocean (northeast of New Zealand). This was smoke from the 04 January outbreak of fires.

GOES-17 True Color RGB images [click to play animation | MP4]

===== 08 January Update =====

GOES-17 True Color RGB images, 05-08 January [click to play animation | MP4]

Full Disk GOES-17 True Color RGB images from the AOS site (above) showed the slow eastward transport of a dense pall of smoke (hazy shades of tan to light brown) across the South Pacific Ocean during the 05-08 January period.

Late in the day, GOES-17 True Color images also showed a small area of smoke drifting southward across the coast of Antarctica (below).

GOES-17 True Color images [click to play animation | MP4]

This was confirmed by the OMPS Aerosol Index product (below), which displayed a small lobe becoming detached from one of the larger smoke features crossing the South Pacific Ocean.

Suomi NPP OMPS Aerosol Index composites, 04-08 January (credit: Colin Seftor, SSAI)

Posted in Antarctic, Aviation, Fire detection, GOES-16, GOES-17, Himawari-8, NOAA-20, RealEarth, Red-Green-Blue (RGB) images, Suomi NPP, VIIRS | No Comments »

Multi-day outbreak of pyrocumulonimbus clouds across southeastern Australia

December 29th, 2019 | Scott Bachmeier

Himawari-8 Shortwave Infrared (3.9 µm, top) and Longwave Infrared Window (10.4 µm, bottom) images [click to play animation | MP4]

JMA Himawari-8 Shortwave Infrared (3.9 µm) and Longwave Infrared Window (10.4 µm) images (above) showed a large bushfire (dark black to red pixels in the 3.9 µm imagery) in far southeastern Victoria, Australia — which quickly burned its way to the coast and produced 3 distinct pulses of pyrocumulonimbus (pyroCb) clouds on 29 December 2019. To be classified as a pyroCb, the deep convective cloud must be generated by a large/hot fire (in this case, the Cann River fire complex), and eventually exhibit cloud-top 10.4 µm infrared brightness temperatures of -40ºC and colder (assuring the heterogeneous nucleation of all supercooled water droplets to ice crystals).

The coldest cloud-top 10.4 µm infrared brightness temperature was -62.6ºC (darker green pixels) at 1650 UTC. According to rawinsonde data from Melbourne (below), this corresponded to an altitude near 13 km.

Plots of rawinsonde data from Melbourne, Australia [click to enlarge]

The long/narrow thermal anomaly of the hot bushfire — which burned southwestward all the way to the coast — was outlined in dark black pixels on VIIRS Infrared Window (11.45 µm) images from NOAA-20 and Suomi NPP, as viewed using RealEarth (below).

VIIRS Infrared Window (11.45 µm) images from NOAA-20 and Suomi NPP [click to enlarge]

===== 30 December Update =====

Himawari-8 Shortwave Infrared (3.9 µm, top) and Longwave Infrared Window (10.4 µm, bottom) images [click to play animation | MP4]

A Himawari-8 Target Sector was positioned over southeastern Australia beginning at 2312 UTC on 29 December, providing images at 2.5-minute intervals — a comparison of Shortwave Infrared and Longwave Infrared Window imagery (above) revealed the formation of several additional pyroCb clouds as southeastern Victoria bushfires continued to grow in number and size. During the daytime, pyroCb cloud tops will appear warmer (darker gray) than those of conventional thunderstorms in the 3.9 µm imagery, due to enhanced reflection of solar radiation off the smaller ice crystals found in the pyroCb anvil. Development of the multiple deep convective pyroCb clouds on this day may have been aided by forcing for ascent provided by an approaching cold front and mid-tropospheric trough, along with favorable upper-tropospheric jet streak dynamics.

The coldest Himawari-8 cloud-top 10.4 µm brightness temperature on 30 December was -73.15ºC at 13:24:41 UTC (violet pixel near the coast); this was 5ºC colder than the coldest temperature of -68.1ºC — at an altitude of 15 km — on 12 UTC rawinsonde data from Melbourne (below). During the 12-hour period between the 2 soundings, the coded tropopause ascended from a height of 13.1 km (-63.7ºC) at 00 UTC to 14.2 km (-67.5ºC) at 12 UTC.

Plots of rawinsonde data from Melbourne, Australia at 00 UTC (yellow) and 12 UTC (cyan) [click to enlarge]

In a toggle between VIIRS Infrared Window (11.45 µm) images from NOAA-20 and Suomi NPP is shown (below), a large pyroCb cloud was seen moving eastward away from the bushfires.

VIIRS Infrared Window (11.45 µm) images from NOAA-20 and Suomi NPP [click to enlarge]

===== 31 December Update =====

Suomi NPP VIIRS Day/Night Band, Shortwave Infrared, Near-Infrared & Active Fire Product images at 1455 UTC on 31 December (credit: William Straka, CIMSS) [click to enlarge]

Suomi NPP VIIRS Day/Night Band (0.7 µm), Shortwave Infrared (3.75 µm and 4.05 µm), Near-Infrared (1.61 µm and 2.25 µm) & Active Fire Product images at 1455 UTC on 31 December (credit: William Straka, CIMSS) [click to enlarge]

Suomi NPP VIIRS Day/Night Band, Shortwave Infrared, Near-Infrared & Active Fire Product images (above) showed nighttime signatures of the widespread bushfires across Victoria and New South Wales at 1455 UTC on 31 December (or 1:55 am local time on 01 January). In the town of Mallacoota, about 4000 people were forced to evacuate their homes and take shelter along the coast (media report). The surface air temperature at Mallacoota Airport briefly increased to 49ºC (120ºF) at 8:00 am local time as the fires approached (below).

Plot shows temperature recorded at #Mallacoota Airport earlier this morning. https://t.co/Qc5Nzwhqr4 Stay up to date @CFA_Updates @vicemergency pic.twitter.com/1eOKky0oAd

— Bureau of Meteorology, Victoria (@BOM_Vic) December 30, 2019

A sequence of daily Aqua MODIS True Color RGB images with an overlay of VIIRS Fire Radiative Power showed the fires and smoke during the 29-31 December period (below).

Aqua MODIS True Color RGB images with an overlay of VIIRS Fire Radiative Power [click to enlarge]

A multi-day Himawari-8 GeoColor animation covering the period 28 December – 01 January is available here.

Posted in Aqua, Fire detection, Himawari-8, MODIS, NOAA-20, RealEarth, Suomi NPP, VIIRS | No Comments »

Pyrocumulonimbus cloud in eastern Australia

November 22nd, 2019 | Scott Bachmeier

Himawari-8 “Red” Visible (0.64 µm, top), Shortwave Infrared (3.9 µm, middle) and “Clean” Infrared Window (10.4 µm, bottom) [click to play animation | MP4]

JMA Himawari-8 AHI “Red” Visible (0.64 µm), Shortwave Infrared (3.9 µm) and “Clean” Infrared Window (10.4 µm) images (above) showed the development of a pyrocumlonimbus (pyroCb) cloud produced by bush fires northwest of Sydney, Australia (station identifier YSSY) on 22 November 2019 (surface analyses). In the 3.9 µm images, hot thermal signatures of the bush fires (darker black to red pixels) were apparent; in addition, the cloud tops of the pyroCb cloud appeared warmer (darker gray) than surrounding convective cloud tops. The pyroCb exhibited cloud-top 10.4 µm brightness temperatures colder than -40ºC.

VIIRS True Color Red-Green-Blue (RGB) and Infrared Window (11.45 µm) images from Suomi NPP and NOAA-20 as viewed using RealEarth are shown below. Cloud-top 11.45 µm brightness temperatures of the pyroCb were in the -70 to -75ºC range on the later 0407 UTC Suomi NPP image.

VIIRS True Color RGB and Infrared Window (11.45 µm) images from Suomi NPP and NOAA-20 [click to enlarge]

The coldest Himawari-8 10.4 µm brightness temperature (BT) associated with the southernmost thunderstorm was -67.0ºC at 0520 UTC (with the northern pyroCb storm, closer to the fire complex, reaching -66.9ºC at 0500 UTC). According to 00 UTC rawinsonde data from nearby Williamtown (below), those BTs were 2-3ºC colder than the coded tropopause temp of -64.5ºC at 12.6 km. The VIIRS 11.45 µm BTs were nearly 10ºC colder than the tropopause, suggesting significant penetration of overshooting tops into the lower stratosphere.

Plot of rawinsonde data from Williamtown, New South Wales [click to enlarge]

Posted in Fire detection, Himawari-8, NOAA-20, RealEarth, Red-Green-Blue (RGB) images, Suomi NPP, VIIRS | No Comments »

Widespread fires across the Deep South

November 19th, 2019 | Scott Bachmeier

GOES-16 Fire Temperature RGB, Shortwave Infrared (3.9 µm), Fire Temperature, Fire Power and Fire Area products [click to play animation | MP4]

A sequence of GOES-16 (GOES-East) Fire Temperature RGB, Shortwave Infrared (3.9 µm), Fire Temperature, Fire Power and Fire Area products (above) displayed signatures of widespread fires — a combination of prescribed burns and agricultural fires — across parts of the Deep South on 19 November 2019. Fire Temperature, Fire Power and Fire Area products are components of the GOES Fire Detection and Characterization Algorithm (SHyMet | ATBD).

GOES-16 “Red” Visible (0.64 µm) images, with and without plots of surface observations, are shown below. While most of the fires were too small/brief to produce large smoke plumes, a prominent plume was associated with one of the hottest and most long-lived fires — which was likely a prescribed burn — in the Chickasawhay State Wildlife Management Area (located east of Hattiesburg/Laurel Airport KPIB) in southeastern Mississippi.

GOES-16 “Red” Visible (0.64 µm) images, with and without plots of surface observations [click to play animation | MP4]

There were no surface stations downwind of that Mississippi fire; however, one small smoke plume drifted over Lafayette in southern Louisiana (KLFT) near the end of the day, briefly reducing the visibility to 6 miles at 22 UTC (below).

Time series of surface observation data from Lafayette Regional Airport in Louisiana [click to enlarge]

For the hot fire in southeastern Mississippi, GOES-16 Shortwave Infrared, Fire Temperature, Fire Power and Fire Area values are shown for the same hot fire pixel at 1716, 1731 and 1806 UTC (below). Note that the individual parameter trends can be different for a given fire pixel — for example, even though the hottest 3.9 µm brightness temperature value was 58.8ºC at 1806 UTC, the peak Fire Temperature value was 1373.1 K at 1731 UTC. However, the time of the maximum Fire Power value of 213.6 MW coincided with the time of the hottest 3.9 µm brightness temperature value (1806 UTC).
