Tropical Cyclone Tino in the South Pacific Ocean

January 16th, 2020 |

Himawari-8

Himawari-8 “Clean” Infrared Window (10.4 µm) images [click to play animation | MP4]

JMA Himawari-8 “Clean” Infrared Window (10.4 µm) images (above) showed the development of Tropical Cyclone Tino in the South Pacific Ocean on 16 January 2020. Tino was moving southeast toward the island nation of Fiji. Convection around the tropical cyclone exhibited extensive cloud-top infrared brightness temperatures (IRBTs) of -90ºC and colder (shades of yellow embedded within the dark purple enhancement), including a few red -100ºC pixels at 1630 UTC.

Plots of rawinsonde data from Fiji (below) showed a tropopause around 100 hPa, where the temperature was around -85ºC — so the tropical overshooting tops with IRBTs in the -90 to -100ºC range were extending into the stratosphere.

Plots of rawinsonde data from Fiji [click to enlarge]

Plots of rawinsonde data from Nandi, Fiji [click to enlarge]

Plots of deep-layer wind shear from the CIMSS Tropical Cyclones site (below) indicated that Tino gradually intensified within a narrow zone of light shear.

Plots of deep-layer wind shear [click to enlarge]

Plots of deep-layer wind shear [click to enlarge]

===== 17 January Update =====

GOES-17

GOES-17 “Clean” Infrared Window (10.35 µm) images [click to play animation | MP4]

A GOES-17 (GOES-West) Mesoscale Domain Sector was positioned over Tropical Cyclone Tino on 17 January, providing images at 1-minute intervals — “Clean” Infrared Window (10.35 µm) images (above) showed the continued development of convective bursts, which at times exhibited IRBT values as cold as -100ºC (red pixels on the coldest portion of the enhancement).

Typhoon Kammuri makes landfall in the Philippines

December 2nd, 2019 |

Himawari-8

Himawari-8 “Clean” Infrared (10.4 µm) images [click to play animation | MP4]

2.5-minute interval rapid scan JMA Himawari-8 AHI “Clean” Infrared (10.4 µm) images (above) showed Typhoon Kammuri as it made landfall in the Philippines around 1500 UTC on 02 December 2019. Kammuri rapidly intensified from a Category 2 to a Category 4 storm (ADT | SATCON) shortly before landfall — it had been moving over very warm water (Sea Surface Temperature | Ocean Heat Content) in the Philippine Sea.

VIIRS Infrared Window (11.45 µm) from Suomi NPP at 1707 UTC and NOAA-20 at 1757 UTC viewed using RealEarth (below) depicted Kammuri 2-3 hours after landfall.

VIIRS Infrared Window (11.45 µm) from Suomi NPP at 1707 UTC and NOAA-20 at 1757 UTC [click to enlarge]

VIIRS Infrared Window (11.45 µm) from Suomi NPP at 1707 UTC and NOAA-20 at 1757 UTC [click to enlarge]

GCOM-W1 AMSR2 Microwave (85 GHz) imagery at 1725 UTC (below) revealed a large eye and nearly circular eyewall.

GCOM-W1 AMSR2 Microwave (85 GHz) image at 1725 UTC [click to enlarge]

GCOM-W1 AMSR2 Microwave (85 GHz) image at 1725 UTC [click to enlarge]

Typhoon Kammuri in the West Pacific Ocean, with record cold cloud-top temperatures

November 30th, 2019 |

Himawari-8 "Clean" Infrared Window (10.4 µm) images [click to play animation | MP4]

Himawari-8 “Clean” Infrared Window (10.4 µm) images [click to play animation | MP4]

2.5-minute interval JMA Himawari-8 AHI “Clean” Infrared Window (10.4 µm) images (above) showed a large canopy of cold cloud-top infrared brightness temperatures (BTs) associated with Category 1 Typhoon Kammuri in the West Pacific Ocean on 30 November 2019. Between 00 UTC and 05 UTC, many of the pulsing overshooting tops exhibited BTs -100ºC or colder (shades of red embedded in black on the coldest end of the scale).

Plots of the coldest overshooting top 10.4 µm brightness temperatures on Himawari-8 Target Sector (2.5-minute interval) and Full Disk (10-minute interval) images during the 0002-0502 UTC time period on 30 November (below) showed that the closest (in time**) Full Disk image BTs were often within a degree C of the Target Sector images — but the magnitude of rapid fluctuations of BT seen in the 2.5-minute data were well not captured by the 10-minute data. For the 4 Target Sector images exhibiting BTs of -103ºC and colder (0112, 0127, 0204 and 0259 UTC) only one of the closely-corresponding Full Disk images exhibited a similarly cold BT (0110 UTC, with -103.0ºC). The coldest Target Sector BT was -103.55ºC at 02:59:44 UTC, while the coldest Full Disk BT was -103.0ºC at 01:13:34 UTC.

**The actual time that closely-corresponding Target Sector and Full Disk scans were imaging Kammuri differed by about 1 minute and 15 seconds — for example, the 01:12:15 UTC Target Sector scanned Kammuri’s coldest overshooting tops at 01:12:19, while the 01:10:00 Full Disk scanned those same overshooting tops at 01:13:34 UTC.

Plots of coldest Himawari-8 10.4 µm brightness temperatures on 2.5-minute Target Sector (blue) and 10-minute Full Disk (green) images [click to enlarge]

Plots of coldest Himawari-8 infrared (10.4 µm) brightness temperatures on 2.5-minute Target Sector (blue) and 10-minute Full Disk (green) images [click to enlarge]

NOAA-20 VIIRS True Color RGB and Infrared Window (11.45 µm) images at 0421 UTC as viewed using RealEarth (below) revealed an area of very cold cloud-top infrared BTs (highlighted by the yellow region near the center of the storm). The coldest BT within that yellow area was -109.35ºC — which would qualify as the coldest cloud-top temperature on record as sensed by a meteorological satellite (Weather Underground). In addition, on the plot of Himawari-8 infrared BTs shown above it can be seen that the previous record for coldest documented BT (-102.2ºC with Tropical Cyclone Hilda in 1990) was eclipsed on 9 Target Sector and 4 Full Disk images.

 NOAA-20 VIIRS True Color RGB and Infrared Window (11.45 µm) images at 0420 UTC [click to enlarge]

NOAA-20 VIIRS True Color RGB and Infrared Window (11.45 µm) images at 0421 UTC [click to enlarge]

The NOAA-20 VIIRS Infrared image at 0421 UTC is shown below with 2 different color enhancements — the darker blue colors of the 160-to-200 K enhancement help to highlight the colder BT regions (including the coldest 163.8 K or -109.35ºC pixel).

NOAA-20 VIIRS Infrared Window (11.45 µm), with different color enhancements (credit: William Straka) [click to enlarge]

NOAA-20 VIIRS Infrared Window (11.45 µm) image at 0421 UTC, with 2 different color enhancements (credit: William Straka, CIMSS) [click to enlarge]

The Himawari-8 Infrared image closest (time-wise) to the NOAA-20 image was at 04:22:15 UTC, and its coldest cloud-top BT was -102.5ºC. In a toggle between magnified Himawari-8 Visible and Infrared images at that time (below), the -102.5ºC BT was located within the northernmost cluster of red pixels (where shadowing and texture in the Visible image highlighted the overshooting top).

Himawari-8 Visible (0.64 µm) and Infrared (10.4 µm) images at 0422 UTC [click to enlarge]

Himawari-8 Visible (0.64 µm) and Infrared (10.4 µm) images at 0422 UTC [click to enlarge]

The nearest upper air site was Babelthuop Airport/Koror on Palau Island, located south of the storm — the coldest temperature in their 00 UTC rawinsonde data (below) was -81.9ºC at an altitude of 16.7 km. Assuming that the overshooting top cooled at a lapse rate of around 7.5ºC per km of ascent beyond the -81.9ºC tropopause (reference), the altitude of the coldest -109.35ºC cloud top was likely near 19.5 km.

Plots of 00 UTC and 12 UTC rawinsonde data from Koror, Palau Island [click to enlarge]

Plots of 00 UTC and 12 UTC rawinsonde data from Koror, Palau Island [click to enlarge]

During the daylight hours on 30 November, Himawari-8 “Red” Visible (0.64 µm) images (below) revealed widespread cloud-top gravity waves which were moving outward away from intense convection with overshooting tops near the storm center. Many of these gravity waves were propagating along the tops of tendrils of transverse banding — especially within the southern semicircle of Kammuri.

Himawari-8

Himawari-8 “Red” Visible (0.64 µm) images [click to play animation | MP4]

—————————

Suomi NPP VIIRS Day/Night Band (0.7 µm) and Infrared Window (11.45 µm) images at 1604 UTC [click to enlarge]

Suomi NPP VIIRS Day/Night Band (0.7 µm) and Infrared Window (11.45 µm) images at 1604 UTC (credit: William Straka, CIMSS) [click to enlarge]

Suomi NPP VIIRS Day/Night Band (0.7 µm) and Infrared Window (11.45 µm) images from Suomi NPP at 1604 UTC (above) and NOAA-20 at 1654 UTC (below) showed mesospheric airglow waves propagating southward in the DNB images.

NOAA-20 Day/Night Band (0.7 µm) and Infrared Window (11.45 µm) images at 1654 UTC (credit: William Straka, CIMSS) [click to enlarge]

NOAA-20 Day/Night Band (0.7 µm) and Infrared Window (11.45 µm) images at 1654 UTC (credit: William Straka, CIMSS) [click to enlarge]

—————————

6.9 µm) images, with contours of Deep-Layer Wind Shear [click to enlarge]

Himawari-8 Water Vapor (6.2 µm) images, with contours of Deep-Layer Wind Shear [click to enlarge]

Himawari-8 Water Vapor (6.2 µm) images with contours of Deep-Layer Wind Shear (above) indicated that Kammuri was moving through an environment of low to moderate shear. Himawari-8 Water Vapor images with plots of satellite-derived Atmospheric Motion Vectors (below) showed a well-defined outflow channel north of the tropical cyclone.

Himawari-8 Water Vapor (6.9 µm) images, with Derived Motion Winds [click to enlarge]

Himawari-8 Water Vapor (6.2 µm) images, with plots of Derived Motion Winds [click to enlarge]


Himawari-8 (courtesy JMA) and GEO-KOMPSAT-2A or GK2A (courtesy KMA) visible imagery were combined to create stereoscopic imagery of the storm on 30 November, as shown below from 2100 UTC on 29 November to 0820 UTC on 30 December.  View the 3-dimensional image by crossing your eyes and focusing on the third image that becomes apparent in between the two images shown.

Visible (0.64 µm) Imagery from Himawari-8 (left) and GK2A (right) from 2100 UTC on 29 November to 0820 UTC on 30 November 2019 (Click to animate)

10-minute Full Disk images of GK2A Cloud Top Temperature and Cloud Top Height products (source) are shown below. A large canopy of CTT values as cold as -80ºC and CTH values up to 15 km were seen associated with Typhoon Kammuri during the period 0000-0500 UTC.

KMA GK2A Cloud Top Temperature product [click to play animation | MP4]

KMA GK2A Cloud Top Temperature product [click to play animation | MP4]

KMA GK2A Cloud Top Height product [click to play animation | MP4]

KMA GK2A Cloud Top Height product [click to play animation | MP4]

Stereoscopic views of Tropical Storm Olga in the Gulf of Mexico

October 25th, 2019 |

GOES-16 (left) and GOES-17 (right) Red Visible (0.64 µm) imagery, 1230 – 2350 UTC on 24 October 2019. To view in three dimensions, cross your eyes until 3 images are apparent, and focus on the image in the middle (Click to animate)

GOES-16 (left) and GOES-17 (right) Red Visible (0.64 µm) imagery, 1240 – 2350 UTC on 25 October 2019. To view in three dimensions, cross your eyes until 3 images are apparent, and focus on the image in the middle (Click to animate)

GOES-16 and GOES-17, although separated by 60 of longitude, can be combined to create stereoscopic imagery in the Gulf of Mexico. The top-most animation, from 24 October 2019, shows the disturbance in the southwest Gulf of Mexico that ulimately becomes Tropical Storm Olga. The bottom animation is from 25 October, a day when the low-level circulation of the storm is apparent.

Tropical Storm Olga is at the northern edge of a very moist airmass as determined from Microwave measurements.  The MIMIC animation, below, from this site, shows the extent of the moist region.  (The moisture associated with Pablo is also apparent)  Dry air moving into the Gulf of Mexico from Texas is restricting the horizontal extent of the moisture. That front moving into the Gulf is expected to overtake Olga as it transitions to an extratropical storm. Heavy rains with this system have already moved into Louisiana and Mississippi.

Microwave-derived Total Precipitable Water, hourly for the 24 hours ending at 21 UTC on 25 October 2019 (Click to enlarge)

For more information on Tropical Storm Olga, refer to the website of the National Hurricane Center. Interests along the Gulf Coast and inland should pay attention to this storm.
